-11- -12-
Cooktop
Screw:M4X50
Screw:M4X8
Countertop
Chassis
Hold down
bracket
■ Step 1: Installing the cooktop
• Locate electrical outlet and gas shut-off valve beneath the cabinet.
• Insert the cooktop centered into the cutout opening. Make sure the front edge of the countertop
is parallel to the cooktop. Make final check that all required clearances are met.
* Be careful that the ignition needle/thermocouple is not damaged by inserting.
• Choose installation to secure the cooktop to the countertop using the two provided hold-down
brackets as shown.
WARNING
Shut off the main gas supply valve before disconnecting the old cooktop and leave it off until the new
hookup has been completed. Don’t forget to relight the burner on other gas appliances when you turn
the gas back on.
Never use an old connector when installing a new cooktop. If the hard-piping method is used, you
must carefully align the pipe; the cooktop cannot be moved after the connection is made.
Tighten all connections if necessary to prevent gas leakage in the cooktop or supply line.
Check for gas leaks: To prevent death, personal injury, explosion, and/or fire hazard, DO NOT use a
flame to check for gas leaks.
■ Step 2: Connecting the cooktop to gas supply
Installation procedure
■ Important safety precautions
● Particular attention shall be given to the relevant requirements regarding ventilation.
● Please make this information available to the person installing the appliance as it could
reduce your installation costs.
● This appliance is to be installed and connected and gas supply only by an authorised person.
● Installation must comply with your local building and local gas authority codes and
electricity regulations.
● Failure to install the appliance correctly could invalidate any warranty or liability claims.
● This gas appliance is suitable for connection to natural gas or LP gas only .If in doubt, refer
to the local gas network operator or gas supplier to confirm gas type at installation site.
■
Before you install the appliance, please make sure that
● The local distribution conditions(nature of gas and pressure) and the adjustment of the
appliance are compatible. For adjustment conditions for this appliance check data plate for
relevant gas information.
● This appliance uses 220-240V 50Hz power supply.
● The supply connection point (gas shut-valve) is accessible after installation. The regulator
supplied with Natural gas appliances must be fitted to the appliance inlet.
● The benchtop is made of a heat resistant material. the installation complies with all the
requirements of Australian and New Zealand Gas Installation Standards (AS/NZS 5601),
including that the product has to be installed so that the surface temperature of any nearby
combustible surface will not exceed 65℃ above ambient. See page 9‘Safety distances’.
■
When you install the appliance
● We do not recommend the use of a down-draught extractor fan with the appliance, as it may
distort the flame pattern, causing uneven heating and reduced cooking performance.
● Where this appliance is installed in marine craft or in caravans, it shall not be used as a
space heater.Only models fitted with the flame failure device can be fitted in marine craft. No
combustible material or products should be placed on this appliance at any time.
● Do not spray aerosols in the vicinity of this appliance while it is in operation.
● If, after following the instructions given, the appliance cannot be adjusted to perform
correctly, please refer to the Service & Warranty book for warranty details and your nearest
Authorised Service Centre,
● Customer Care, or contact our local distributors.
Installation instructions
