Technical Data
Installation instructions
Technical Data
WARNING
Explosion Hazard
Install a shut-off valve.
Securely tighten all gas connections.
If connected to LP, have a qualified person make sure gas pressure does not exceed 3.5 kPa.
Examples of qualified person include:
Licensed heating personnel
Authorized gas company personnel, and
Authorized service personnel.
Failure to do so can result in death, explosion, or fire.
WARNING
The pressure regulator located at the inlet of the cooktop manifold must remain in the supply
line regardless of whether natural or LP gas is being used.
■ Gas supply requirements
■ This appliance is suitable for use with a flexible hose assembly
Hose assembly must comply with AS/NZS 1869, 10mm ID, Class B or D, maximum length 1.0m,
and installed in accordance with AS/NZS 5601.1 . It should be suitable for connection to a fixed
consumer piping outlet located at the region shown in figure 1.and should be suitable for
connection to the inlet connection behind the appliance shown in figure 2. The supply connection
point can be accessible with the appliance installed.
Warning: Ensure hose assembly is restrained from accidental contact with the flue outlet
of an under bench oven.
Provide adequate gas supply
This cooktop is designed to operate at a pressure of 1.0 kPa on natural gas or 2.75 kPa on LP gas.
Make sure you are supplying your cooktop with the type of gas for which it is designed. Do not attempt
to convert the appliance from the gas specified in this manual to a different gas without consulting the
gas supplier.
This cooktop is convertible for use on natural or ULPG gas. If you decide to use this cooktop on LP
gas, conversion must be made by a qualified LP installer before attempting to operate the cooktop.
Content
Model
Wok
Voltage
Material
Features
Flame safeguard
Colours
Gas types
"NG,(LP conversion
kit supplied)"
"NG,(LP conversion
kit supplied)"
Cooktop dimensions mm
Cut-out dimensions mm
Energy rating (NG) MJ/h
Nozzle diameter(NG) mm
"NG,(LP conversion
kit supplied)"
GLG90305&GLG90305-Y
Tri-ring
220-240V
Glass
Intelligent timing
Yes
Black
GLG90505
Tri-ring
220-240V
Glass
Intelligent timing
Yes
Black
GLG60305&GLG60305-Y
Tri-ring
220-240V
Glass
Intelligent timing
Yes
Black
Wok burner
Rapid burner
Semi-rapid burner
Auxiliary burner
Total MJ/h
23
14.5
6.5
NA
44
23
14.5
6.5*2
3.5
54
23
14.5
NA
3.5
41
Wok burner
Rapid burner
Semi-rapid burner
Auxiliary burner
1.4*2&1.15
1.74
1.15
NA
1.4*2&1.15
1.74
1.15
0.85
1.4*2&1.15
1.74
NA
0.85
Width
Depth
Height
900
520
122
900
520
122
600
520
122
Width
Depth
816
460
844
488
554
478
Packing list
Packing list
Cooktop 1
Nozzel
Needle
1
User
Manual
1
Grates
3
2
LP Conversion
Kits
1
Rapid grate
2
Screw 4
Pressure
regulator
1
Warranty
Card
Other Other
Other
GLG60305
GLG60305-Y
GLG60305
GLG60305-Y
GLG60305
GLG60305-Y
1
Hold down
bracket
2
0
Cut-out
Template
1
1
NOTE Rapid grate only for rapid burner and semi-rapid burner.
