LPG conversion
-31- -32-
LPG conversion
Step 4: Take off all the knobs.
Step 5: Disassemble the panel
Using Phillips screwdriver unscrews the panel screws, then lift off the panel.
3/16” flat-blade
screwdriver
bypass screw
Step 7: Adjust bypass screw
Turn all flow adjusting screws clockwise to
tighten using a 3/16" -head screwdriver. The
flow of the wok burner, rapid burner and
semi-rapid burner is regulated by the screw
and it needs to rotate 45° counterclockwise
Step 8: Put the cooktop panel, burner heads, burner caps, knobs, and grate back into
place correctly.
Thermocouple
Step 6: Put the burner heads and burner caps into burner manifold cup. And
connect the timing control board.
Orifice size
0.7mm or 0.73mm
(GLG60305&GLG60305-Y)
0.7mm or 0.73mm
(GLG60305&GLG60305-Y)
0.6mm
Step 3: Using Phillips screwdriver take off the bracket, then using a 9/32” or 7mm open-end
wrench, remove the burner orifice from the bottom of center burner manifold cup. And replace the
LP burner nozzles.
