-19- -20-
Operation instructions
Operation instructions
The panel includes two parts, the buttons and the display. In the upper row, there are 3-digit timing
nixie tubes (in minute) for the left burner and the middle burner from the left to the right. In the
lower row, there are timing minus button for the left burner, timing plus button for the left burner,
timing minus button for the middle burner, and timing plus button for the middle burner from the
left to the right.
Description of the panel
Wok burner Other burner
7
8
■ Layout
Turn the control knobs to adjust the flame level. Turn the knob counterclockwise, 90° for high flame,
and 170° for low flame.
The Center knob controls the Tri-Ring burner. The Tri-Ring burner consists of 3 rings of fire. The
outer ring is controlled separately, and the two inner rings are adjusted simultaneously. When the
knob is turned to 90° all three rings of fire will be at the maximum state achieving 23 MJ/h. If you
continue to turn the center knob from 90° to 170° the outer fire ring fades out gradually and then the
inner flames begin to diminish. At a full 170° the inner flame rings are at a minimum flame state.
Turn the knob back to any position between 90° and OFF and the outer ring and 2 inner rings of fire
change synchronously to ensure that the pot is evenly heated.
■ Knob control
1.Wok burner:23MJ/h
2.Semi-rapid burner:6.5MJ/h
3.Rapid burner:14.5MJ/h
4.Auxiliary burner:3.5MJ/h
5.Rapid grate
6.Knobs
7.Thermocouple
8.lgnition device
1 2 3
246
GLG90505 GLG90305&GLG90305-Y
1 2 3
56
5
1 3
4
5
6
GLG60305&GLG60305-Y
GLG90505
GLG90305
GLG90305-Y
GLG60305
GLG60305-Y
■ Timer function
Note: Only the left and middle burners of GLG90305&GLG90305-Y and the left and RF
burners of GLG90505&GLG60305&GLG60305-Y support the timer function.
Note: The cooktop with the timer function could cut off the gas supply with a delay. After the
gas supply is turned off automatically, the user needs to reset the control knob to the
closed position. When the timer function is enabled, the user shall not leave the place to
avoid the cooktop being left unattended.
Note: The touch button may fail if the panel is stained by oil or water. Please keep the panel
clean and dry.
If the flame goes out accidentally a safety device will be activated about 45 seconds later and
automatically cut off the gas supply to the cooktop even if the burner knob is still on. If this
happens, turn the burner knob to the OFF position, wait 60 seconds, and then try to relight the
burner.
■ Flame Failure Device
Take note which knob controls which burner. This appliance is equipped with an electronic ignition
device. Simply press the knob downward and turn it counterclockwise to HI until the burner lights.
If it does not light within the first 15 seconds, turn the knob to OFF and wait for 60 seconds before
attempting to light it again. This cooktop has a fast ignition device. When the knob is released, the
solenoid valve will not cut off power immediately. It will still maintain continuous current to provide
energy to the ignition needle. Therefore, the igniter will continue to maintain the ignition state for
1 to 3 seconds, which provides better ignition rate.
■ Fast Ignition
