- 20 -
360
280
The center
line
6. Installation of the exhaust duct: if the common ue interface or wall hole is larger than the diameter of
the aluminum foil exhaust duct, the aluminum foil exhaust duct can be directly connected. If the common
ue interface or wall hole is smaller than the diameter of the aluminum foil exhaust duct, the exhaust
duct adapter shall be tted on the end of the aluminum foil exhaust duct without plastic xing ring, and
shall be glued and sealed with adhesive tape. The small end of the exhaust duct adapter has two outer
diameter specications of 150mm and 125mm. Please cut off the excess part smaller than the common
ue interface or wall hole according to the actual situation;
Φ178
Φ140
Φ115
For the adhesive tape and
exhaust duct adapter
The end with a diameter smaller
than the wall hole shall be cut off
Foil tape
Notes: a. The joint between the exhaust duct and the common ue or the wall hole must be tightly
sealed to prevent smoke leakage, and the exhaust duct should not be squeezed,
deformed or turned at a small angle. The number of bending should no more than one,
and the extraction hose should be straight;
b. The diameter of the common ue interface or wall hole should be basically the same as the
diameter of the exhaust duct and should not be too small, otherwise it will cause poor
smoke exhaust, increased noise and reduced air volume.
7. Installation of the exhaust hood: x the exhaust hood and sealing ring at the air outlet
of the main body with 8 exhaust hood screws (M4 × 18 mm);
The bevel
should towards
the electrical box
8. Remove the protective lm from the top plate surface;
