Assembly instructions
GB
Electrical connection
• The electrical connection must be carried out by a quali-
fied electrician who is authorised to carry out such work!
• Statutory regulations and the connection specifications issued
by the local power supply company must be strictly observed.
• When connecting the appliance it must be ensured that there
is a device which makes it possible to disconnect it from the
mains at all poles with a contact opening width of at least
3 mm. Line-protecting switches, fuses or contactors are suita-
ble cut-out devices.
When connecting and repairing the appliance disconnect it
from the electricity supply with one of these devices.
• Any superfluous cable must be removed from the installation
area beneath the appliance.
• Full protection against accidental contact must be ensured on
installation.
Glass ceramic hob connected to the electrical supply of a
cooker
• Connect the unit plug of the hob to the oven located below it.
The plug and the sockets have a reverse polarity protection
system and/or coloured markings in order to prevent any mix-
ups.
Push the plug lightly into the corresponding socket on the oven
and allow it to lock into place.
• Connect the earthed conductor.
Technical data
GKT 604 ES
GKT 642 ES
GKUT 642 ES
All of the cooking zones are equipped with HiLight heating
elements.
Hob dimensions
Height/ Width/ Depth. . . . . . . mm
Installation dimensions
Width/ Depth. . . . . . . . . . . . . mm
45 x 580 x 510
560 x 490
Cooking zones
front left. . . . . . . . . . . . Ø cm / kW
back left . . . . . . . . . . . Ø cm / kW
back right . . . . . . . . . . Ø cm / kW
front right. . . . . . . . . . . Ø cm / kW
18/ 1.8
18/ 1.8
21/ 2.3
14.5/ 1.2
Heating element rated voltage
Hob
total . . . . . . . . . . . . . . . . . kW
400V
7.1
Hob dimensions
Height/ Width/ Depth. . . . . . . mm
Installation dimensions
Width/ Depth. . . . . . . . . . . . . mm
45 x 580 x 510
560 x 490
Cooking zones
front left. . . . . . . . . . . . Ø cm / kW
back left . . . . . . . . . . . Ø cm / kW
back right . . . . . . . . . . Ø cm / kW
front right. . . . . . . . . . . Ø cm / kW
12-18/ 1.7
18/ 1.8
12-21/ 2.2
14.5/ 1.2
Heating element rated voltage
Hob
total . . . . . . . . . . . . . . . . . kW
400V
6.9
Hob dimensions
Height/ Width/ Depth. . . . . . . mm
Installation dimensions
Width/ Depth. . . . . . . . . . . . . mm
45 x 605 x 545
560 x 490
Cooking zones
front left. . . . . . . . . . . . Ø cm / kW
back left . . . . . . . . . . . Ø cm / kW
back right . . . . . . . . . . Ø cm / kW
front right. . . . . . . . . . . Ø cm / kW
12-18/ 1.7
18/ 1.8
12-21/ 2.2
14.5/ 1.2
Heating element rated voltage
Hob
total . . . . . . . . . . . . . . . . . kW
400V
6.9
