EN
- 13 -
TECHNICAL SPECIFICATIONS
TDO-45
FEATURES Invisible loudspeaker with 70 and 100 V line transformer
Plasterboard panel installation, with accessories for installation in 12.5 mm plasterboard.
Sound is produced via radiating surface vibration.
Non-directional sound.
Long product life.
POWER 60 W maximum, 40 W RMS
DRIVERS 4
RESPONSE 140-20,000 Hz
IMPEDANCE 40 W RMS@100V (250 Ω)
SENSITIVITY 90 dB ±3 dB at1 W/1 m
DISPERSION 180º
MATERIAL Aluminium
DIMENSIONS 300 x 400 x 50 mm depth
WEIGHT 1.45 kg
ACCESSORIES 1 cutting template
4 MDF wood installation dowels with foam
8 screws
OPTIONAL TDO-45BOX: installation box
TDO-45BOX
FEATURES Installation box for invisible loudspeaker TDO-45.
DIMENSIONS 304 x 450 x 71 mm depth
WEIGHT 1.5 kg
ACCESSORIES 8 Drywall screws 50 mm
4 Self-tapping screws 20 mm
1 Installation template 306 x 406 mm
