- Ordem de prioridade:
A entrada REMOTE MUTE atenua todas as entradas exceto a entrada EMERGENCY IN quando se fecha
os contactos dos seus terminais.
1.- A entrada EMERGENCY IN tem a prioridade máxima, atenuando as restantes entradas quando esta
tem sinal.
2.- A entrada ZONE MICROPHONE tem prioridade sobre todas as entradas exceto a entrada
EMERGENCY IN.
3.- A entrada REMOTE WALL PANEL tem prioridade sobre todas as entradas exceto a entrada
EMERGENCY IN.
4.- A entrada CH 1|PAGING MIC tem prioridade sobre as entradas CH 2, CH 3,
CH 4,
CH 5, AUX 1-3 e
o reprodutor.
5.- As entradas CH 2, CH 3, CH 4 e CH 5 têm prioridade sobre as entradas AUX e o reprodutor.
6.- As entradas AUX e o reprodutor não têm prioridade sobre nenhum outro sinal.
PRIORIDADE 3.º FIO
Para ligação com atenuadores por três fi os
como o DOT-12TR. Quando existir sinal no PIN
3WIRE, que contém o sinal de áudio 100 V, este
irá passar diretamente à coluna sem nenhum
tipo de atenuação.
PRIORIDADE 24 V
Para ligação com atenuadores por quatro fi os
como o DOT-12TR. Quando o PIN 3WIRE
fornecer um sinal de 24 V CC, o sinal do
amplifi cador que passe pelo atenuador irá
passar diretamente à coluna sem nenhum tipo
de atenuação.
3-WIRE CONNECTION
