EN
- 7 -
TECHNICAL SPECIFICATIONS
FORCE-X12DSP FORCE-X15DSP
FEATURES High power active speaker.
DSP processor.
Colour display screen.
4 equalisations: Music, Club, Live and
Speech
Bluetooth v5.3 receiver
TWS function.
Compact and lightweight case.
Aluminium rear panel.
Front LED with different switching options
(On, Off or limiter).
Carrying handles.
Hole in the base for 35 mm tube.
High power active speaker.
DSP processor.
Colour display screen.
4 equalisations: Music, Club, Live and
Speech
Bluetooth v5.3 receiver
TWS function.
Compact and lightweight case.
Aluminium rear panel.
Front LED with different switching options
(On, Off or limiter).
Carrying handles.
Hole in the base for 35 mm tube.
AMPLIFIER 1,200 W Peak
350 W RMS
2-way (bass: 300 W + treble: 50 W)
Class D
1,400 W Peak
500 W RMS
2-way (bass: 440 W + treble: 60 W)
Class D
PROTECTION Temperature (85ºC) and overload Temperature (85ºC) and overload
LOUDSPEAKERS 1 x high-capacity 12” woofer: coil 65 mm,
ferrite magnet 170 x 20 mm
1 x compressor driver: 1” mouth, 34 mm
coil, ferrite magnet 90 x 15 mm
1 x high-capacity 15” woofer: coil 75 mm,
ferrite magnet 180 x 20 mm
1 x compressor driver: 1” mouth, 44 mm
coil, ferrite magnet 115 x 15 mm
RESPONSE 50-20.000 Hz 45-20.000 Hz
INPUTS CH 1 balanced mic/line. Combo connector
(XLR + 6.3 mm jack), AUX jack TRS 3.5 mm
and Bluetooth
CH 2 balanced mic/line. Combo connector
(XLR + 6.3 mm jack)
Mic signal level: 40 mV RMS (-28 dBV) /
600 Ω
Line signal level: 350 mV RMS (-9 dBV) /
100k Ω
AUX signal level: 350 mV RMS (-9 dBV) /
100k Ω
CH 1 balanced mic/line. Combo connector
(XLR + 6.3 mm jack), AUX jack TRS 3.5 mm
and Bluetooth
CH 2 balanced mic/line. Combo connector
(XLR + 6.3 mm jack)
Mic signal level: 40 mV RMS (-28 dBV) /
600 Ω
Line signal level: 350 mV RMS (-9 dBV) /
100k Ω
AUX signal level: 350 mV RMS (-9 dBV) /
100k Ω
OUTPUTS 1 x balanced line. XLR connector. MIX
mode (CH 1 + CH 2) or LINK (direct output
from CH 2 input)
1 x balanced line. XLR connector. MIX
mode (CH 1 + CH 2) or LINK (direct output
from CH 2 input)
SENSITIVITY 97 dB a 1 W/1 m 99 dB at 1 W/1 m
SOUND PRESSURE 122 dB @ maximum power at 1 m 125 dB @ maximum power at 1 m
DISPERSION 90º H x 60º V 90º H x 60º V
SUSPENSION
POINTS
2 x M8 points (top and side) 2 x M8 points (top and side)
POWER SUPPLY 230/115 V AC, 300 W
Fuse T6.5AL, 250V
230/115 V AC, 500 W
Fuse T10AL, 250V
DIMENSIONS 350 x 600 x 350 mm depth 425 x 685 x 385 mm depth
SIMPLIFIED EU DECLARATION OF CONFORMITY
FONESTAR SISTEMAS S.A. hereby declares that the FORCE-X12DSP and FORCE-X15DSP loudspeakers are compliant with the
Directive 2014/53/EU.
The complete text of the EU Declaration of Conformity is available at the following internet address:
fonestar.com/en/FORCE-X12DSP
fonestar.com/en/FORCE-X15DSP
