9
100-T UL SERIES
Manuel d'utilisation / User manual
100 ICS6-T UL 100 IC8-T UL
Type
In-ceiling - 2-way coaxial bass-reflex
100V/70V or 8Ω installations - Steel
back can
In-ceiling - 2-way coaxial bass-reflex
100V/70V or 8Ω installations - Steel back can
Drivers
6
1/2
" (16.5cm) Polyglass Midbass
1" (25mm) Al inverted dome Tweeter
8" (21cm) Polyglass Midbass
1" (25mm) Al Inverted dome Tweeter
Sensitivity (2.83V/1m) 89dB 91dB
Frequency response (+/-3dB) 70Hz - 23kHz 53Hz - 23kHz
Low frequency point (-6dB) 60Hz 48Hz
Max rated power 30W (max power tap or 8Ω tap) 60W (max power tap or 8Ω tap)
SPL at max rated power 102dB @1m 104dB @1m
Directivity ±65° (-6dB) ±65° (-6dB)
70V line power 4/8/15W 8/15/30W
100V line power 8/15/30W 15/30/60W
8Ω Recommended
amplifier power
15 - 100W 15 - 100W
Dimensions (ØxDepth) 11
3/4
"x5
1/16
"(297x129mm) 1
3/4
"x8
7/8
" (297 x 225mm)
Cut-out diameter 10
3/8
" (265mm) 10
3/8
" (265mm)
Depth from wall 4'' (103mm) 8
3/8
'' (212mm)
Ceiling thickness 0 - 1
3/8
" (0 - 36mm) 0-1
3/8
" (0 - 36mm)
Net weight (with grille) 8.26lbs (3.75kg) 10.5lbs (4.75kg)
Packaging dimensions 14⅝"x14⅝"x6¾" (375x373x172mm) 14⅝" x 14⅝" x 11⅜" (370 x 370 x 290mm)
Total weight (with packaging) 10.8lbs (4.9kg) 13.5lbs (6.15kg)
Certifications UL 1480 UL 2043 UL 1480 UL 2043
Terminal black, wire size 28AWG to 12AWG 28AWG to 12AWG
Operating temperature range 41-96°F (5-35°C) 41-96°F (5-35°C)
Storage temperature 32-122°F (0-50°C) 32-122°F (0-50°C)
