EN
22
100-T UL SERIES
User manual
INSTALLATION
Existing construction
• Before installing the loudspeakers, make sure that the corresponding positions on the ceiling are not
obstructed by the routing of a ventilation duct or any cable that could interfere with the installation. Use
the appropriate tools to help you determine suitable locations.
• Make sure the ceiling is thick/deep enough to allow installation of the product.
• Using the cut-out template supplied, trace the flush-mounting outline on the existing ceiling.
Then cut along the line with an appropriate tool to create an opening in the ceiling (fig.3).
• Do not install the speakers before laying the cables. Make sure you leave enough cable length to easily
connect your product (about 19 3/4” /50cm) We recommend using a cable with a marker that ensures the
polarity of the speaker drivers is respected. Choose quality cables with the appropriate cross-section for
the length: your dealer will be able to advise you.
• Add the supplied safety sling to attach your product securely to the ceiling (figs. 8, 9). Each loudspeaker
must be connected to the supporting structure and, if the system allows, via 2 separate points of the
structure.
• The loudspeaker is fastened to the ceiling using rotating brackets. To do this, place the loudspeaker into
the cut-out opening and turn the screw on the mounting brackets clockwise to tighten it using a Phillips
screwdriver or a screw-gun. Make sure the tightening torque is set to a low value, to avoid damaging the
fastening brackets (fig 10). The loudspeaker will be sufficiently fastened when resistance is felt at the end
of tightening.
New construction
• Use the specific optional mounting kit.
• Prepare the cables and make sure you leave enough cable length to easily connect your product (about
19 3/4” /50cm). We recommend using a cable with a marker to ensure the polarity of the speaker drivers
is respected (+/-). Choose quality cables with a cross-section appropriate to the length. You dealer will be
able to advise you.
• The loudspeaker is fixed to the ceiling using rotating brackets. To do this, place the loudspeaker into
the cut-out opening and turn the screw on the mounting brackets clockwise to tighten it using a Phillips
screwdriver or a screw-gun. If a screwdriver is used, ensure that the tightening torque is set to a low value,
to avoid damaging the fastening lugs (fig. 10). The loudspeaker is adequately attached when you feel
resistance at the end of tightening.
Power settings
The transformer power settings for each product are on the front panel (fig. 11).
