7
Acoustic Imager
Hand Strap/Neck Strap
Hand Strap/Neck Strap
The Imager includes a hand strap and a neck strap that makes it
easy to hold and operate as you take measurements. See Figure 2
for information about setup.
Figure 2. Hand Strap/Neck Strap
Display
The color display is a touchscreen that shows the test area as a
visual image combined with a sound image. See Table 3.
With the touchscreen you are able to set up and adjust all the test
parameters. For more information, see Basic Operation.
Table 3. Touchscreen
1 2 3
459 8 7 6
Item Description
Tool Menu
Zoom
Capture Mode
Frequency Range of Spectrum
Palette of dB SPL Scale
Prole Selection (when enabled)
Folder Selection
Time/Date Stamp
Battery Status
