Earth Ground Clamp

Equipment and Environment

7

Equipment and Environment

For the ac leakage current verification, adjustment, and performance test, use the Fluke 5522A with a 2-turn

current loop. Connect the AUX terminal or 20 A terminal to the LO terminal. To short the two terminals, use

a conductor with two banana jacks at both ends.

For the Ω verification, adjustment, and performance test, use the precision decade resistance box with a

1-loop short copper wire to form a resistance loop.

Table 2 is a list of specifications.

Table 2. Environment Specifications

Setup

Before you start the verification procedures or make calibration adjustments, refer to this section for the

equipment, system, and setup requirements.

See Table 3 for a list of requirements for the verification tests and calibration adjustment.

Table 3. Equipment Requirements

CAL Point Accuracy Unit

Minimum Required

Characteristics

IET 1433-20

0.100 1.5 % 0.020 0.022

Ω

5.38 % 2.01 %

0.250 1.5 % 0.020 0.024 2.38 % 0.81 %

0.500 1.5 % 0.050 0.058 2.88 % 0.41 %

1.000 1.5 % 0.050 0.065 1.63 % 0.21 %

2.000 1.5 % 0.100 0.130 1.63 % 0.11 %

5.000 1.5 % 0.100 0.175 0.88 % 0.05 %

10.00 1.5 % 0.10 0.25 0.63 % 0.03 %

20.00 1.5 % 0.30 0.6 0.75 % 0.02 %

50.00 1.5 % 0.30 1.05 0.53 % 0.01 %

100.0 1.5 % 0.50 2.0 0.50 % 0.01 %

200.0 3 % 1.0 7.0 0.88 % 0.01 %

400 5 % 5.0 25 1.56 % 0.01 %

600 10 % 10 70 2.92 % 0.01 %

1000 20 % 0 200 5.00 % 0.01 %

Equipment Description

Recommended

Model

Used on:

Verification

Tests

Calibration

Adjustment

Current Calibrator Calibrator Fluke 5522A

XX

Current Wired Coil 2-Turn Loop insulated copper wire

XX

OHM Calibrator

Precision decade resistance box

IET 1433-20 or equivalent

XX

OHM Wired Coil

1-Loop short copper wire

XX
