DIOPTER ADJUSTMENT
The diopter is the measurement of the eye’s curvature. Every eye is curved differently. Fireeld
Barrage Riescopes have a diopter adjustment to help the shooter attain a clear, crisp sight picture.
If the image does not appear clear and crisp, rotate the diopter adjustment clockwise or counter-
clockwise until a sharp sight picture and reticle are achieved, then tighten the eyepiece lock ring. This
adjustment should stay the same unless the riescope’s operator changes.
OPERATING THE ILLUMINATED
Fireeld Barrage Riescopes feature an illuminated reticle. Illuminating
the reticle improves visual distinction between the target and the
reticle, especially in low light conditions. The reticle can be used in
the following states: black (off), red or green (illuminated). Reticle
illumination includes ve brightness settings for each color red/green.
To illuminate the reticle:
1) Rotate the reticle illumination adjustment (7) turret located on the
left side of the riescope.
12
