a
h
[m/s
2
] K [m/s
2
]
Gripping surface =3.5 2.0
Handle <2.5 1.5
The specified emission levels (vibration, noise)
– are used to compare machines.
– They are also used for making preliminary estimates
regarding vibration and noise load during operation.
– They represent the primary applications of the power
tool.
CAUTION
The emission values may deviate from the specified
values. This is dependent on how the tool is used and
the type of workpiece being machined.
► Assess the actual load during the entire operating
cycle.
► Determine suitable safety measures depending on
the actual load.
3 Intended use
The cordless planer is designed for machining wood, soft
plastics and wood-based materials. Only use the cordless
planer with Festool insertion tools.
The cordless planer is not suitable for planing wet wood.
The user is liable for improper or non-intended use.
4 Technical data
Cordless planer HLC82EB
Motor voltage 18V
Speed (no-load)n
0
11,500rpm
Compatible battery packs Festool BP18≥4Ah series*
Planing width 82mm
Planing depth 0–2.5mm
Max.rebatedepth 25mm
Weight excl. battery pack 2.7kg
*To ensure maximum performance of the HLC82EB, a
≥5,0AhHP battery pack is recommended.
5 Parts of the device
[1-1]
Cover for spiral blade
[1-2]
Small lever for changing the extractor
connector side
[1-3]
Buttons to release the battery pack
[1-4]
Handle
[1-5]
Elbow connector for attaching suction hose
[1-6]
Extractor connector
[1-7]
Mark to read off the chip depth
[1-8]
Rotary knob for chip depth adjustment/gripping
surface
[1-9]
Scale for chip depth
[1-10]
Safety lock
[1-11]
On/off switch
[1-12]
Support foot
[1-13]
Planing head
Accessories shown or described are not always included
in the scope of delivery.
The specified illustrations appear at the beginning of the
Operating Instructions.
6 Commissioning
6.1 Switching on/off
Switching on
► Press down on the safety lock[1-10].
► Press and hold the on/off switch[1-11].
Switching off
► Release the on/off switch[1-11].
7 Battery pack
Before using the battery pack, check that the battery
interface is clean. Any contamination of the battery
interface may impair correct contact and lead to the
contacts being damaged.
A faulty contact may result in the machine overheating or
being damaged.
[2A]
Remove the battery pack.
[2B]
c
lick
Insert the battery pack until it clicks
into place.
Further information about the charger and battery
pack can be found in the corresponding operating
manual.
8 Settings
WARNING
Risk of injury
► Remove the battery pack from the power tool before
performing any work on the power tool.
8.1 Electronics
The power tool features full-wave electronics with the
following properties:
Temperature cut-out
The power tool switches off if a certain temperature is
exceeded. To restart the power tool, turn the on/off
switch off and back on again. If the power tool does not
start and an acoustic signal sounds, the power tool has
overheated, see9.1.
Brake
The power tool has an electronic brake. After switching
off, the spiral blade is electronically braked to a standstill
in approx. two seconds.
8.2 Festoolapp*
The power tool can be configured with the Festoolapp.
To do this, the battery pack used must be a Bluetooth
®
battery pack.
The battery pack is connected via Bluetooth
®
, see
the operating manual for the battery pack.
*Not available in all countries.
8.3 Setting the chip depth
► Set the chip depth using the rotary knob[1-8].
English
16
