Installation

Damage to the device due to non-approved potentials at the pins

• Power connection:

• Do not connect pin3

• Logic connection:

•

Apply the logic supply [Logic Pin 1] and the IO-Link communication signal C/Q [Pin 3] at least

50 ms after the load supply 24 V DC [Power Pin 1]. For example, ensure the switch-on delay by

interposing relay contacts.

• Disconnect the logic supply [Logic Pin 1] and the IO-Link communication signal C/Q [Pin 3] after a

shutdown, after an interruption or before restoring the load supply 24 V DC [Power Pin 1].

• EMCS-ST is not hot-plug capable: 24V level to the digital outputs DO1/DO2 [Pin 2/3] or the

IO-Link communication signal C/Q [Pin 3] only after connecting the reference potentials GND/L–

[Pin 4/8].

• Disconnect the digital outputs DO1/DO2 [Pin 2/3] and the IO-Link communication signal C/Q

[Pin 3] at least 50 ms before the power supply connections GND/L– [Pin 4/8] and 24VDC/L+

Disconnect [Pin 1]. For example, ensure the switch-off delay by interposing relay contacts.

• GND and L– connections:

• Apply the Power, GND [Pin 2] and Logic, GND/L– [Pin 4/8] connections to one potential.

Forexample, ensure the same potential by using a common fixed power supply or an electrical

connection of the two 0 V DC GND potentials.

Connect the power cable to the [Power] connection of the integrated drive EMCS-ST and to a PELV

fixed power supply.

Connect the logic cable to the [Logic] connection of the integrated drive EMCS-ST and to a

controller or to a IO-Link master.

Wiring diagram: DIO operation (digital I/O)

In NPN mode defined levels must be applied to the DI1/DI2 digital inputs of the EMCS, e.g.by

controller outputs with pull-up resistors (4.3kW recommended).
