53
EN
TP3 COND
cod. 3541T740 - Rev 05 - 08/2022
TP3 COND 820 1000
Gas category
Pmax Pmin Pmax Pmin
Heat input (kW) . 767 498 935 608 Qn (Hi)
Effective rated output (80/60°C) (kW) 752 489 916 595 P 80° - 60°
Effective rated output (50/30°C) (kW)
Gas 820 533 1000 650 P 50° - 30°
Oil 793.5 516.7 967.7 630 P 50° - 30°
Efficiency (80/60°C) (%) 98.7 98.2 98.8 97.8
Efficiency (50/30°C) (%)
Gas 106 107 106 107
Oil 102.5 104 102.5 104
Efficiency 30%
Gas 107.5 107.5
Oil
104.5 104.5
NOx class
Gas 5 5 NOx
Oil 1 1 NOx
Fuel consumption Max. output
Gas (G20) m3/h 81.2 99
Oil kg/h 64.7 78.8
Max. working pressure bar 6 6 PMW
Max. heating temperature °C
95 95 tmáx
Heating water content liters 1450 1565
Pressure loss on fume side mbar
6 6.4
Pmax Pmin Pmax Pmin
Flue gas temp. (80/60)
Gas ºC 72 58 73 62
Oil ºC 753 57 75 63
Flue gas temp. (50/30)
Gas ºC
50 32 50 33
Oil ºC 51 33 51 33
Fume flow rate
Gas Kg/h 1176 764 1434 932
Oil Kg/h 1172 761 1428 929
Fume flow rate
Gas g/s 327 213 398 259
Oil g/s 325 211 396 257
CO2
Gas % 10 10 10 10
Oil % 13 13 13 13
Protection rating IPX0D
Electrical power supply V/Hz 230/50 230/50
Empty weight kg 2050 2150
Sizes
A mm
1180 1180
B mm 1424 1424
C mm 2620 2760
D mm 1120 1120
E mm 2006 2006
G mm 2075 2075
H mm 2094 2244
I mm 224 224
J mm 650 650
K mm 300 450
L mm 600 600
M mm 320 320
N mm 278 2783
O mm 262 262
P mm 2068 2216
Q mm 226 226
S mm 78 78
V mm 830 830
W mm 1480 1480
Firebox internal diameter L2 Ø mm
700 700
Firebox length L1 mm 1980 2130
Nozzle max. diameter L3 Ø mm 270 270
Nozzle min. length mm 320 320
Heating delivery T1 DN 125 DN 125
High temperature heating return T2 DN 65 DN 65
Low temperature heating return T3
DN 125 DN 125
Expansion vessel connection T4 DN 80 DN 80
Boiler discharge connection T5 1”1/2 1”1/2
Flue connection T6 Øe mm 350 350
