Technical data
ADAT I/O optical Toslink interfaces (2 x in, 2 x out)
- 16x16 channels with 32 kHz, 44.1 kHz, 48 kHz
- 8x8 channels with 64 kHz, 88.2 kHz, 96 kHz
- 4x4 with 128 kHz, 176.4 kHz, 192 kHz
Latency: 3 Samples
Wordclock BNC sockets for IN and OUT, 75 Ohm termination of input
switchable
MIDI I/O
3.5mm jacks for MIDI-IN and MIDI-OUT, adapter to MIDI-5Pin
optionally available.
Pin assignment follows the MIDI 2.0 Type A standard
Outputs
(analog)
8 x jack 6.3mm, balanced TSR
Maximum output level +20dBu
Digital gain 0dB to -28dB in 1dB steps
SNR 120dB (typ.)
THD+N -115dB (1kHz, 48kHz SR, a-weighted, typ.)
Inputs
(analog)
8 x jack 6.3mm, balanced TSR
Maximum input level +20dBu
Digital gain: 0dB to +28dB in 1dB steps
SNR 112dB (typ.)
THD+N -108dB (1kHz, 48kHz SR, a-weighted, typ.)
D/A
Converters ES9017: 32Bit/192kHz ESS D/A Converter
A/D Converters
ES9840Q: 32Bit/192kHz ESS A/D Converter
Display TFT Screen (3", IPS technology)
USB
USB-C connector for MIDI-over-USB (class compliant)
Headphones 6.3mm jack output, gain power adjustable in four stages,
digital Volume adjustment in 1dB steps.
Dedicated path via separate ESS DAC
21
TECHNICAL DATA
FERROFISH PULSE8 AE 8x8 Channel A/D-D/A Converter & Router
