Page 17 of 30
minutes into the refrigeration cycle (e.g. if the air stream probe measures 42°F/5.6°C or greater and the defrost
probe measures 20°F/-6.7°C or lower for five minutes). Once initiated the defrost cycle will terminate when
evaporator coil sensor reaches 43°F (6.1°C).
If a manual defrost is required, one can be initiated by pressing and holding the down arrow for three (3) seconds.
This is typically unnecessary and should only be performed if special circumstances require it.
10.6 CONTROL PARAMETERS
Table 2 - Control Parameters
Parameter Description UCR, UCRSL
Control Setpoint →
1
2
3
4
5
6
7
8
9
Compressor Cut out [°F]
32.0
30.0
28.0
26.0
24.0
22.0
20.0
18.0
16.0
Compressor Cut in [°F]
39.0°
Compressor Min On Time
10 min
Compressor Min Off Time
3 min
Compressor Max Run Time
90 min
Defrost Termination Temp [°F]
43.0
Time to first defrost
8 hr.
Time to subsequent defrost
8 hr.
Maximum Defrost duration
30 min
Defrost on demand differential [°F]
20.0
Delay for defrost on demand
5 min
Time delay to the next defrost on demand
30 min
Table 3 - Temperature Probe Common Resistance Chart
Probe Temp
Maximum Resistance
[Ω]
Normal Resistance [Ω]
Minimum Resistance [Ω]
32°F (0°C)
27.83
27.28
26.74
77°F (25°C)
10.1
10
9.9
212°F (100°C)
1
0.97
0.94
10.7 INITIAL STARTUP
After all the checks outlined in the installation section of this manual have been made, the case is ready to be put into
service. Turn on the Power at the breaker box and flip the Power Switch and Light Switch on unit to the on position. Also
ensure that the control is powered on as described above.
At start up from a warm unit, it is recommended that the temperature control is set to a warmer setting, such as 1. After
the unit has gone through several cycles, adjust the control to a mid-range setting, then to a colder setting if necessary to
maintain desired product temperature
NOTICE:
This refrigerated display case is designed to operate in a maximum environment of 75°F (23.9°C)
and 55% relative humidity. Exceeding these limits will cause poor case performance and excessive
sweating.
