REFRIGERATION
Self Contained Models Use pressure gauges to set pressure control.
SSRC3652
SSRC5052
SSRC5952
SSRC7752
Refrigeration R404 Charge
30 OZ
32 OZ
34 OZ
36 OZ
Low Pressure Switch Cut In
80 psi
80 psi
80 psi
80 psi
Low Pressure Switch Cut Out
20 psi
20 psi
20 psi
20 psi
High Pressure Switch Cut Out
400 psi
The self-contained models are shipped from the factory with a completely operational 404A refrigeration
system and require no modifications or adjustments upon installation. Case must be installed as per the
installation section of this manual to provide proper condensing air cooling.
Self Contained Refrigeration Operation
The unit temperature is controlled by the low pressure side of a dual high/low pressure switch. The
compressor will run until either the minimum run timer times out (approx 10 min) or the suction pressure
reaches the set cut out point at which time the compressor turns off. The compressor will remain off until
the suction pressure rises and reaches the set cut in point of the pressure switch at which time the
compressor turns on.
Note: The condenser fan runs continuously.
This unit also has a defrost timer that will shut the compressor off a set number of times per day to insure a
full defrost occurs. The compressor will remain off until the either the off time is reached or until the
temperature sensor on the coil reaches a set temperature which ever happens first.
Remote Models Use pressure gauges to set pressure control.
SSRC3652
SSRC5052
SSRC5952
SSRC7752
Refrigeration R404 Charge
CHARGED IN FIELD
Remote Low Press. Switch Cut In
50
Remote Low Press. Switch Cut Out
15
Remote High Press. Switch Cut Out
400 psi
Remote Models
The remote models are designed to use 404A refrigerant and shipped from the factory with the evaporator
coil, expansion valve, drier filter, sight glass and refrigerant solenoid valve. A thermostat senses evaporator
temperature and opens and closes the refrigerant solenoid valve. The solenoid valve closes and shuts off the
refrigeration flow to the unit and initiates a pump down cycle. This will allow the remote low pressure
switch to open and shut off remote compressor. The temperature control may require some adjustment by
installer for proper operation of unit. This unit also has a defrost timer that will shut the refrigeration
solenoid off a set number of times per day (set at factory for 3 times per day) to insure a full defrost occurs.
The solenoid will remain off until the either the off time is reached or until the temperature sensor on the
coil reaches a set temperature which ever happens first
The condensing unit is optionally supplied from the factory for remote location installation. The
condensing unit supplied from the factory will include a high low pressure switch that must be mounted
