36
-
Special Length Shelf Installation
LONG SHELF BRACKET
TOP THUMB SCREW
LOWER THUMB SCREW
SHELF STANDARD
If the top shelf has long brackets and needs to be placed in top shelf standard notch position the shelf
bracket may hit top panel or divider panel when trying to install it. If top slot is required install bracket as
follows:
1. Remove the shelving from cases.
2. Loosen bottom thumb screw (do not remove)
3. Remove top thumb screw
4. Rotate the shelf standard towards center of case until the shelf bracket can be slipped into
slots of standard.
5. Once shelf bracket is in place, rotate the shelf standard back to vertical position and reinstall
top thumb screw and tighten.
6. Tighten lower thumb screw and install shelving as described in shelving installation.
LED Light Plug Connection
LED LIGHT
LED LIGHT CORD
"B" SHAPED PLUG
NOTICE: The plug must be inserted in correct orientation into LED light.
LED light will not light if Connecting plug into LED light upside
down. It may also cause LED light failure.
Look at the end of the plug and the receptacle of LED light. On one side of the LED plug there are two
bumps and the other side there is a flat. (Similar to the letter B shape). The LED light has the same
configuration. The shapes must align correctly when inserting LED plug into the LED light.
