28
-
Joining Cases (Single Glass End Between)
GLASS PANEL IS ATTACHED
TO RIGHT SIDE CASE AT FACTORY
ALIGN CASES AND ATTACH WITH
(4) 1/4-20 X 1/2 SCREWS.
1. If cases are a Counter Top Models, cut holes in counter top as shown in Cabinet Preparation section
In this manual.
If cases are a Floor Models, the cases are joined in the same manner but bases will also need to be
joined as described in next section.
2 Push cases together and align front and rear of cases. Be sure case surfaces are tight together.
3. Attach the cases together with (4) 1/4-20 screws provided. Do not use screws to pull cases together.
Glass bushing may strip or glass may break. If these are Floor Model cases do not tighten screws until
completing The Joining Floor Model Base Section.
