Weekly Cleaning
This procedure is recommended on a weekly basis. It may need to be performed more often if
necessary to maintain a clean, sanitary case. The case should be cleaned to this procedure before
using the first time.
NOTICE:
Avoid splashing or soaking any electrical components with water to
prevent electrical damage to the case.
NOTICE:
Shut off lights and power switches and remove all product from case.
Allow sufficient time for the unit to reach room temperature before
proceeding with cleaning.
NOTICE:
Remove all product from case before proceeding with cleaning
procedure.
DISPLAY PAN
AIR DEFLECTOR
(Service Unit Only)
THUMB SCREWS
EVAPORATOR SHROUD
SHOWN WITHOUT FRONT GLASS &
END PANELS FOR ILLUSTRATION
ONLY
1. Remove both rear doors as described in the “Door Removal” section of this manual.
2. Remove shelving from unit through rear door opening as described in the “Shelving Installation and
Removal” section of this manual. Remove all interior shelving as described in the shelving
installation and removal section of this manual.
3. Remove both shelf standards from interior of case by removing the (2) thumbscrew from top and
bottom.
4. Steps 5 & 6 on refrigerated only.
5. On Refrigerated models lift the display pan up and out of evaporator tub. Remove display pan
through rear opening. Remove the evaporator fan shroud by removing the thumbscrews along the
backside of evaporator fan shroud and on each end of evaporator coil. Lift the rear of the
evaporator fan shroud and reach in and unplug the evaporator fan motor cord. Remove evaporator
fan shroud through rear opening.
6.
Clean the entire interior of the case using warm soapy water. Wipe off all soapy water with a damp
cloth and allow to dry. (DO NOT use solvents such as Acetone, Benzene, Carbon Tetrachloride, and
Lacquer Thinners)
NOTE: Depending on the amount of usage and spillage of foreign material, some fasteners may have
to be removed and parts disassembled to allow proper cleaning of the unit.
