27

SPECIFICATIONS

DM-S8208

Mic Station

AUDIO SPECIFICATIONS

Audio output 1.2V +/-200mV balanced

Input Sensitivity/impedance

MIC: -60dB/600Ω ( balanced )

AUX: -10dB/10KΩ ( unbalanced )

Frequency response (+/- 3dB )

MIC: 100Hz-15KHz ; AUX: 20Hz-20KHz

T.H.D MIC: < 0,5% ; AUX: <0,2 %

S/N MIC: >50dB ; AUX: >80dB

INPUTS / OUTPUTS

Aux IN XLR connector

Mic IN 3,5mm jack

Link IN 1x RJ45

Link OUT 1x RJ45

MICROPHONE SPECIFICATIONS

Directional Characteristics Cardioid Electret Condenser

Frequency Response 30Hz-20KHz

Output Impedance 200Ohm

Sensitivity -40dB±2dB(0dB=1V/Pa at 1KHz)

Current Consumption Max. 0.5mA

GENERAL

Control Protocol RS-485

Power Supply 24VDC 500mA

Operating Temperature -10° to +40°

Storage Temperature -20° to +60°

Net Dimensions 264x135x62mm ( 10,4x5,3x2,4 inch ) [WxHxD]

Net Weight 1020g ( 2,2lb )
