17

DM-8208 SOFTWARE

OPERATION

An intuitive user interface (UI) is provided for quick and easy control of

main functions. UI is consisted of the most essential and frequently used

functions for operation.

• Matrix mode and mix mode can be selected for each output chan-

nel. The default setting is in matrix mode.

- Matrix mode: Only one input can be selected. Press the arrows

icon to check the available inputs.

- Mix mode: It is a function to mix and broadcast multiple inputs.

When you press the Mix button, the Mix icon is highlighted and the

Mix mode is activated. When you open the settings window, you can

mix multiple inputs. Adjust the volume of the input to mix and then

press the Close button to complete the setting.

• You can adjust the volume fader up or down for each output chan-

nel. The fader moves from -90.00dB to 0.00dB.

• Mute On / Off is available for each output channel.

• A total of eight preset buttons are provided. You can use it after

setting preset in Setup.

• Click the house icon in the lower left corner to return to the main

category

SCHEDULE

Scheduler enables scheduled broadcasts to match the desired date and

time. It is available in an intuitive calendar form for easy and convenient

use of scheduled broadcasts.

• Schedule setting and schedule view are available by Day, Week,

Month and Agenda.

• A list of reservation settings can be viewed at once in the Agenda

tab.

• Double-click the desired date to proceed with the reservation

setting.

• You can select the current date, select the next day / the previous

day, and select a specic day / week / month / year through naviga-

tion in the upper left corner.

• Start setting / editing the schedule.

• Enter the reservation setting title. Fill in the text. (ex. lunch time)

• Set the start and end times. Detailed settings can be adjusted ma-

nually or via the right icon (calendar, clock).

• Set the repeating. It can be set by Day, Week, Month,

and Year. The detailed settings of the repeat cycle are shown below

- Weekly: You can set multiple specic days for each week.

- Monthly: You can set a specic day by month.

- By Year: You can set a specic date for each year.

• Select the audio le that will be output on the scheduled. Multiple

selections are available.

• You can select multiple audio outputs to be reserved.

• Please refer to [picture_ #1] for selecting / editing audio les.

• The selected audio le can be set to Repeat Playback or Shufe

Playback.

• You can select multiple output channels for scheduled broadcasting.

• You can execute “Logic out” when reservation broadcast is execu-

ted. It has a total of 8 contact outputs and can select multiple.

• Reservation details can be entered as text in the description eld.

• When the reservation setting / editing is completed,

press the SAVE button to nish.
