- 22
ENG
C820RQ
Power supply
230 V - 50 Hz
2 AA 1.5 V alkaline batteries
Battery life > 1 year
Adjustment ON / OFF or TPI
Max. power consumption 1 W
LED switch-off 5 ÷ 10 s from last press
Temperature adjustment range 2 ÷ 40 °C; increments of 0.1 °C
Measurement range / Room T display -9 to +50 °C; resolution 0.1 °C
Temperature display Celsius
Relay output with changeover dry contacts 5(3)A 230 Vca
Microdisconnection 1 B.U.
Nominal conductor wire gauge
for flexible cables
0.5 to 1 mm
2
Minimum adjusting differential STD; (0.3 ÷ 5) °C
Thermal gradient of reference 4 K/h
Maximum room temperature 45°C
Storage temperature -10 ÷ +60 °C
Software Class A
Insulation class Class II
Protection rating IP32
Degree of pollution 2
Mounting
Wall-mounting or on a Flush-mounting box
type 500-502-503
Dimensions
98 x 98 x 20 mm (square base)
125 x 98 x 20 mm (rectangular base)
Weight 0.100 kg
Compliant with standards: EN 60730-1 and parts two;
Directive 2014/30/EU (EMC); Directive 2014/35/EU (LVD);
ErP classification: ErP Class IV, 2 % (Reg. EU 811/2013 - 813/2013).
Product manufactured in Italy.
1 - TECHNICAL DATA
