C800WIFIOTRQ
- 6
ENG
LOW BATTERY WARNING
• 1 flash per minute on display in Stand-by: the batteries are
running low and it is still possible to operate the device but they
need to be replaced.
• 1 flash per minute and Low Bat appears on the display in Stand-
by: the batteries are exhausted the device can no longer be
operated and will go to OFF.
Batteries can be replaced at any time without losing the stored
settings.
Insert the cables coming out
from the C800AL power supply
unit to the C800WIFIOTRQ
base.
Power supply
3.3 Vdc
Bus connection
Note: Use the square base
for 500 and 502 flush-
mounting boxes and the
rectangular base for 503
flush-mounting box (see
page 11).
It is possible to power the device
using the C800AL power supply
unit (optional) which requires the
flush-mounting.
Unscrew the screw as shown in
the drawing and lower the plas-
tic cover to gain access to the
terminal block for the electrical
connections.
MAINS POWER SUPPLY 230V - 50Hz
