38
INSTALLATION
Making the worktop recess
l A distance must be maintained between the countertop surface and the oven/divider, in
accordance with the dimension indicated in the drawing.
l There should be sucient spacing around the opening, in particular, at least 50 mm distance
to the wall and 60 mm distance to the front edge of worktop.
l The distance between the edge of the opening and the side wall of the furniture should be
minimum 55 mm.
l Worktop must be made of materials, including veneer and adhesives, resistant to a tem-
perature of 100°C. Otherwise, veneer could come o or surface of the worktop become
deformed.
l Edge of the opening should be sealed with suitable materials to prevent ingress of water.
l Worktop opening must cut to dimensions as shown on gure 1.
l Ensure minimum clearance of 25 mm below the hob to allow proper air circulation and
prevent overheating. See Figure 2.
1
560
490
min
60
min
50
