4
Single cooking area (220x197 mm) 2100 W, with
3000 W Booster function
5
Control panel
6
Suction grid
1 + 2
Combinable cooking area (220 x 395 mm) 3000 W,
with 3700 W Booster function.
3 + 4
Combinable cooking area (220 x 395 mm) 3000 W,
with 3700 W Booster function.
INDICATORS
Pan detection
Each of the cooking areas is fitted with a
system to detect the presence of a pan.
The pan presence detection system re-
cognises pans with a magnetic base,
suitable for use with induction hobs.
If the pan is removed during cooking or
if an unsuitable pan is used, the sym-
bol appears on the display.
Residual heat indicator
The residual heat indicator is a safety
feature, indicating that the surface of the
cooking area is still at a temperature of
50°C or above, which may cause burns
if touched with bare hands. The digit for
the corresponding cooking area indic-
ates .
8. CONTROL PANEL
1
10 9
8
3 4 5
13
1112
7
A
2
6
1
On/Off
2
Grease filter saturation indicator
3
Cooking zone power level indicator
4
Suction hood power level indicator
5
Suction hood timer control
6
Suction hood controls zone symbol
7
Cooking zone timer control
8
Time management zone
9
Activated Carbon filter saturation indicator
10
Defrost key
11
Lock key
12
Pause key
13
Swipe keyboard
A
Auto key
The cooking areas can be activated by
pressing the reference digit . The digit
becomes brighter to confirm the opera-
tion.
When a pan is placed on one of the 4
cooking areas, the hob automatically
detects its presence and lights up the
corresponding digit to activate it.
If there are no pans or other objects on
the hob, the digits are not visible.
The functions which can be selected are
always visible on the control panel, but
with a dimmed light. Select the functions
by touching the corresponding symbol.
Turning on the appliance:
Press and hold the On/Off button for 2 seconds to turn the
hob on and to activate its functions.
At this point the hob is on but all the cooking areas and the
hood are at zero power. The Hob will switch off automatic-
ally after 20 seconds if it is not being used.
Attention: For safety reasons the hob can always be
turned off using the On/Off button.
Attention: The functions that can be selected will always
be the ones that are illuminated/visible on the control panel,
and these will always be the only ones that can be activ-
ated.
The controls for the cooking areas, suction hood and timer
can be activated by pressing on the reference Digit.
The Digit lights up more intensely to confirm the operation.
9. POWER LIMITATION
When connecting to the domestic power
supply for the first time, the installer
must set the power of the cooking areas
based on the actual capacity of the do-
mestic power supply.
9
