44
Version 07/11 - Page 6
INSTALLATION
COMBINATIONS HOOD AND MOTOR KITS
CHOOSE A BLOWER FOR YOUR HOOD
After choosing the hood width and depth for your cooking
needs, next choose the type of blower appropriate for
your cooking.
NOTE: no other blower is
compatible with this hood, except for the
kits below.
# IB300 - Internal Blower Kit 300 cfm
# IB600 - Internal Blower Kit 600 cfm
# IB1200 - Internal Blower Kit 1200 cfm
# RB900 - Remote Blower Kit 900 cfm
# RB1200 - Remote Blower Kit 1200 cfm
# INLBKIT - In Line Blower Kit
(supply own in-line blower)
OPTIONAL ACCESSORIES AVAILABLE
• *Charcoal Filter
* it is highly recommended that professional style cooking always be
vented to the outside; for recirculating installations only, some ductwork is
required to exhaust the unit out of the cabinet. Replace as needed with the
same model
part # FILTER1
NOTE: The charcoal filter kit for use with the 300 / 600
cfm internal blower kit ONLY
CAUTION - To reduce risk of fire and electric shock, install this rangehood only with: Remote blower manufacturer by Faber
models RB900 and RB1200 or Integral blower manufactured by Faber models IB300 or IB600 or IB1200 or with INLBKIT and
generic in-line blower rated max 4.2 A suitable for use with solid state variable speed control
INLBKIT
PRECAUCIÓN - Para reducir el riesgo de incendio y descarga eléctrica, instale esta campana extractora úni-
camente con un ventilador fabricado por Faber que sea modelo RB900 y RB1200, o ventiladores internos
fabricados por Faber que sean modelo IB300, IB400, IB600 o IB1200 con el kit accesorio INLBKIT comprado
porseparado.Alutilizarunventiladorenlíneaounventiladorremoto,debetenerunvoltajemáximode4,2
A adecuado para utilizarlo con un control de velocidad variable de estado sólido y para utilizarlo con el kit
accesorio INBKLIT comprado por separado.
Para el Inca de 30", se recomienda que los ventiladores se mantengan a un MÁXIMO
de 600 CFM.
INSTALACIÓN
COMBINACIONES DE LOS KITS DE EXTRACTOR Y MOTOR
IB300 o IB400 o IB600
(KIT1VENTILADOR)
