DIMENSIONS
# FILTER1 –
Charcoal Filter Kit
High quality charcoal lter for use
when recirculating the air back
into the kitchen. Filters out odor
and should be replaced every 6
months
PERFORMANCE
SPECIFICATIONS
SPEED 1 2 3 BOOST
CFM 150 295 395 560
Sones 2.8 4.3 6.0 7.5
ACCESSORIES
cut out dimensions
21" - 19 11/16" w x 10 1/4" d
28" - 26 11/16" w x 10 1/4" d
35" - 32 11/16" w x 10 1/4" d
convertible to ductless /
recirculating
yes – with FILTER1 / FILTER1LL2
body depth|height 11 1/4" 12 1/8
Variable Air Management Yes- (set to 295, 395, 600 CFM)
controls 4 speed electronic w/ white LED
lighting LED light bar
ducting top 6" round
grease filters dishwasher safe mesh
perimetric filtration system yes
10 minute intensive speed yes
15 minute auto shut off yes
ADA compliant yes - remote included
power cord included yes
AC power 400 watts / 3.2 amps
# WIREBOX –
Fixed Wiring Box
Replace the power cord with a
hard wired box to power the range
hood
# MUDAMPER6 / MUDAMPER8 –
Universal Make-Up Air Damper
Satises make-up air requirements,
this kit uses an air switch to activate
the make-up air damper to open and
bring fresh air into the home when
the hood fan is on. It then closes
tightly when the hood is off. The
CFM level is not reduced with this
accessory.
# FILTER1LL2 –
Long Lasting Charcoal Filter
Kit
New washable charcoal lter
can be recharged and washed
up to 8 times. For use when
recirculating the air back into the
kitchen. Filters out odor and can
last up to 4 years.
INCA IN-LIGHT
INSERT RANGE HOOD
Overall
# LINE24ST –
Stainless Steel Liner 24"
(INLT28SSV ONLY)
See page 3 for more information.
# LINE30ST / LINE36ST –
Stainless Steel Liner 30 & 36"
(INLT28SSV ONLY)
See page 3 for more information.
# LINSPT301228 –
Stainless Steel Self Supporting
Liner 30"
(INLT28SSV ONLY)
See page 3 for more information.
# LINSPT361228 –
Stainless Steel Self Supporting
Liner 36"
(INLT28SSV ONLY)
See page 3 for more information.
12
1
2
The Hood can be installed directly on the underside of the cabinet.
If you use the Self supporting liner #LINSPT301228 or
#LINSPT361228, please follow the instructions included in the
corresponding self supporting liner manual.
If you do not use the Self supporting liner, create a cut out in the
bottom of the cabinet as shown in the illustration.
PREPARING THE CABINET
21"
28"
35"
Cut Out
Product specifications are subject to change without notification. Consult
the installation instructions before you begin installing this range hood.
*Check local make up air codes for guidelines.
Imagined in Italy
# LINE36PT-
Stainless Steel Liner 36''
(INLT35SSV ONLY)
See page 3 for more information
Rev: 04/29/21
