Combo mode (“bridge”
function)
This function allows 2 cooking areas to be combined to use and control them as if they were one
and have a bigger cooking area at your disposal. This function allows you to use pans with a wider
base.
Only the cooking zones on the left can be selected for use with this function.
To enable/disable: press the digits of the left-hand cooking areas at the same time to select the 2
areas be combined until the digit appears to show that the function has been enabled. The other
digit is used to set the power level.
AUTO function
“A”
The standard setting when the hob/suction hood is switched on is for the hood to start up in auto-
matic mode with the LED “A” brightly lit. The Hood comes into operation if the power in the cooking
areas is greater than “1”.
It is deactivated by pressing the LED “A” which changes intensity from bright to dim in confirmation.
It can also be deactivated by pressing a value, higher than “1”, on the power bar, which is con-
firmed by the fact that the LED “A” changes intensity from bright to dim.
It is reactivated by pressing the LED “A” which changes to brightly lit.
11. COOKING TABLE
Power level Cooking method To be used for
1
Melting, heating gently Butter, chocolate, gelatine, sauces
2
Melting, heating gently Butter, chocolate, gelatine, sauces
3
Warming up Rice
4
Prolonged cooking, thickening, stewing Vegetables, potatoes, sauces, fruit, fish
5
Prolonged cooking, thickening, stewing Vegetables, potatoes, sauces, fruit, fish
6
Prolonged cooking, braising Pasta, soups, braised meat
7
Light frying Rösti (potato fry-ups), omelettes, breaded and fried
foods, sausages
8
Frying, deep fat frying Meat, chips
9
Quick frying at high temperature Steak
P
Quick heating Boiling water
12. SUCTION HOOD
FUNCTIONS
The controls for the cooking areas, suction hood and timer
can be activated by pressing on the reference Digit.
“ 9 ”
Press “9” on the power bar to set INTENSIVE 1
speed. This setting is timed to operate for 10
minutes. Once this time has passed, the system
will automatically return to the speed set previ-
ously. It is deactivated by selecting a different
speed.
“ P ”
Press “9” on the power bar twice to set INTENSIVE
2 speed. This setting is timed to operate for 5
minutes. Once this time has passed, the system
will automatically return to the speed set previ-
ously. It is deactivated by selecting a different
speed.
Func-
tion
Delay
This function is only available if Automatic mode is
deactivated. Automatic mode is deactivated by
pressing “A”.
Press the suction hood Digit and set a speed on
the power bar.
Press the Timer management Digit, which was dis-
playing “CL” but will change to the countdown. This
is pre-set to 15 minutes.
Timer symbol
After selecting the suction hood Digit, press the
Timer Management Digit to set the countdown.
Grease filter maintenance symbol
The grease filter cleaning signal is displayed by
LED and it is always enabled.
Filter reset and reactivation
After having carried out maintenance on the filter:
press and hold for 5 seconds. - The LED of the
grease filter will turn off and the countdown will re-
start.
Charcoal filter maintenance symbol
The hood is set by default to ducting mode. With
no loads on, press the Hood controls digit to en-
able the suction hood. Press and hold the Digit
again for 5 seconds to:
Activate the charcoal filter:
The charcoal (odour) filter symbol lights up for 1
second.
Deactivate the charcoal filter:
The charcoal (odour) filter symbol flashes twice.
After activation, the icon will light up to indicate that
maintenance must be carried out on the charcoal
(odour) filter.
Reset and reactivation of the charcoal filter
After having carried out maintenance on the filter:
press and hold for 5 seconds. - The LED of the
anti-odour filter will turn off and the countdown will
restart.
12
