The cooking areas can be activated by
pressing the reference digit
. The digit
becomes brighter to confirm the opera-
tion.
When a pan is placed on one of the 4
cooking areas, the hob automatically de-
tects its presence and lights up the cor-
responding digit to activate it.
If there are no pans or other objects on
the hob, the digits are not visible.
The functions which can be selected are
always visible on the control panel, but
with a dimmed light. Select the functions
by touching the corresponding symbol.
7. POWER LIMITATION
When connecting to the domestic power
supply for the first time, the installer must
set the power of the cooking areas based
on the actual capacity of the domestic
power supply.
If this is not necessary, the hob can be
turned on directly using
, otherwise,
follow the operations below to access the
menu.
Before carrying out the procedure it is
advisable to read the entire paragraph.
Connect the hob to the domestic mains
power.
1. All the digits light up for a few
seconds, then switch off and only
keeps flashing.
2. Press and hold
: the digits in the
cooking area indicate
.
3. Keep pressing
and start press-
ing the digits in the areas in anti-
clockwise order starting from the
front right one.
1
2
4
3
The rear left digit indicates and a num-
ber indicating the type of menu. The front
left digit indicates a number which de-
pends on the parameters indicated in the
selection.
Select the digit with
and press “8” in the
power bar.
Select the front left digit and select the
correct setting.
See the following table for the specifica-
tions:
Value on the
power bar
KW Notes
0 7.4
Standard initial setting
1 6
2 5
3 4
4 3.5
5 3
6 2.5
Once the correct value has been
entered, confirm by touching and holding
.
10
