Vertical and Horizontal Ducted Venting Installation with the optional Kit Chimney
Remove the 4 screws as shown and take off the cover plates.
Do not discard and set aside for future use.
)URPLQVLGHWKHKRRGXVHDÀDWKHDGVFUHZGULYHUDV
shown in image above, to disconnect the left and right
Connectors from the blower.
12
3
Open the panel, unlock the security cable as shown.
5HPRYHWKH¿OWHUVE\SXVKLQJWKHOHYHUWRZDUGVWKH
back of the unit and at the same time pulling downward.
'RQRWGLVFDUGWKH¿OWHUVDQGVHWDVLGHIRUIXWXUHXVH
Installation with the optional Kit Chimney - Preparation of Hood
