TLI Pro 201 • Introduction 1
Introduction
This guide describes the function, installation, and operation of the TLI Pro 201. Unless otherwise stated, the
terms “interface” and “TouchLink Pro interface” also refer to this model.
This section provides an overview of the TLI Pro 201:
• About the TLI Pro 201
• Features
• Application Diagram
About the TLI Pro 201
The Extron TLI Pro 201 is a TouchLink Interface that allows a third-party 4K touchscreen display to be used as a
point of control within an Extron Pro Series control system. The interface includes a scaled HDCP 2.3-compliant
HDMI input for video preview, supporting resolutions up to 4K @ 30 Hz. The scaled output supports signal
resolutions up to 4K @ 30 Hz at 4:4:4.
Features
• Utilize a third-party 4K touchscreen display as a point of control within an Extron Pro Series control
system.
• Compatible with third-party touchscreen displays up to 4K/30 at 4:4:4.
• Compatible with all IP Link Pro control processors and HC 400 Series Meeting Space Collaboration
Systems.
• HDCP 2.3 compliant HDMI Input for full-motion video preview and monitoring.
• One high speed USB 2.0 port — For third-party touch displays or HID support.
• PoE+ compatible — Product is powered directly by a PoE+ switch or injector, eliminating the need for bulky
local power supplies.
• Universal interactive display driver — Embedded driver that supports most interactive displays right out of
the box.
• Fully customizable using Extron control system software — GUI Designer combined with Global
Configurator Plus, Global Configurator Professional, or Global Scripter.
• Uses the same HID device drivers as the Annotator 300 and TLI Pro 101.
• Advanced Extron video signal processing with a high-performance scaling engine.
• Fast processing and ample memory.
• Automatic clock synchronization — Allows touchpanel to display the accurate time and date.
• Adjustable sleep timer puts interface into sleep mode.
• Compact 1 inch (25 mm) high, half rack width metal enclosure low profile enclosure — Allows discreet
installation within a lectern or behind a flat panel display.
