Network Button Panels • Firmware Updates 61
Firmware Updates
If the need arises, you can replace the NBP rmware. This section covers the following rmware-related topics:
• Determining the Firmware Version
• Updating the Firmware
Determining the Firmware Version
To check which rmware version the button panel is using, do one of the following:
• View the device information in Toolbelt.
• View the general status information section of the NBP embedded web page.
Before using those methods, connect the NBP and the PC to the same network. For details see the Hardware
Features and Installation — Wall-mountable Models section starting on page 9, Hardware Features and
Installation — NBP 1200C on page 28, and the Software-based Conguration and Control section starting
on page 52.
Using Toolbelt Software
1. Open the Toolbelt software.
2. Either add the desired NBP manually or start device discovery and select the desired device from the list of
discovered devices.
3. Click on the IP address link or on the
Manage
icon (gear) in the row for the desired control processor, select
the applicable device management tabs, and view the device information.
Using a Browser
The NBP comes with a factory default embedded web page where you can check the rmware version as follows:
1. Start a browser program.
2. Type the IP address of the NBP into the address eld of the browser and log on to the internal web page.
3. Look for the version within one of the information panes.
Updating the Firmware
Firmware upgrade tools require the PC and the NBP to both be connected to an Ethernet network. The
instructions for updating the rmware assume you have installed the appropriate software on your PC rst.
NOTES:
• You should save the existing configuration to a file (see the Global Configurator Help File for instructions)
before replacing the firmware. If the file is saved, the configuration can be restored to the control
processor or collaboration system receiver later using GC.
• Check the Extron website for firmware-related documents, instructions, patch files, and new firmware files
before loading new firmware. We recommend that you read the firmware release notes (available from
www.extron.com) before beginning the firmware update.
Rev. C: Modified the wording of step 3 to reflect current Toolbelt software:
4. Click on the IP address link or on the
Manage
icon (cog) in
the row for the desired controller, select the applicable device
management tabs, and view the device information.
09/06/19: Am changing “cog” to “gear”.
Rev. E: Modified wording for
where to find FW version.
