Network Button Panels • Software-Based Configuration and Control 53
Basic Setup Steps: a Guide to this Section and Other Resources
NOTE: GC projects can be created offline and uploaded to the hardware at a later date.
Follow the steps in Hardware Features and Installation — Wall-mountable Models on page 9 or in
Hardware Features and Installation — NBP 1200C on page 28. The overall process for setting up a button
panel and system is as follows:
Step 5: Configure the IP settings of each
NBP and of the control processor.
See the network
communication
setup instructions
Create a new GC Professional or GC Plus project
and add the control processor to it.
Congure ports.
Add NBP button panels and congure the buttons.
Step 7: Test the system,
make adjustments, nalize conguration.
Save the project.
Step 4: Cable the NBPs and the control processor,
then apply power.
Cable all other devices.
Step 2: Prepare the installation site.
Step 1: Get ready.
Step 3: Change buttons or faceplates, if desired.
Step 8: Mount the NBPs.
Create monitors, schedules, timers, macros,
and local variables.
Build and upload the conguration to
the control processor.
If desired or required, install a new
security certicate (via Toolbelt).
Within Global Configurator
(GC Professional or
GC Plus mode):
Step 6
Figure 60. Overall Configuration Steps
Downloading the Software and Getting Started
Software updates and a large variety of device drivers can be downloaded from the
Download
page on the Extron
website (www.extron.com/download/index.aspx). When you locate the desired software or driver package,
follow the on-screen directions to download and install it.
Locating Software, Firmware, and Driver Files on the Extron Website
There are three main ways to nd software, rmware, and device drivers within www.extron.com:
• Via links from the web page for the specific product
• Via the Download Center page (click on the
Download
tab at the top of any page within the Extron website.)
• Via links from search results
NOTE: For some software you have the option to click the
Download
button to begin downloading the
software file. For other software there is a link for contacting an Extron support representative who can
provide you access to the latest version.
To obtain Extron control product software, you must have an Extron Insider account. Extron provides
training to our customers on how to use the software. For Global Configurator Professional, you must first
attend Extron training, pass a proficiency test, and achieve Extron Control Professional Certification before
being able to access all the features of that program.
60
network
communication
setup instructions
on page24
