Network Button Panels • Operation 51
NBP Series Reset Mode Summary
Mode
Use This
Mode to...
Activation Result
Use Factory Firmware
Temporarily
boot up the unit
with factory-
installed
firmware for a
single power
cycle in the
event that
a firmware
update has
failed or if
incompatibility
issues arise
with user-
loaded
firmware
To start the Use Factory Firmware reset mode and replace firmware:
1. On the NBP, press and hold the recessed
Reset
button while
applying power to the unit. Keep holding the button down until
the
Reset
LED blinks twice, then release the button. The LED
blinks slowly during bootup. The unit enters factory firmware
mode.
2. Upload new firmware to the unit as desired (see Updating the
Firmware on page 61 for details).
NOTE: Do not continue to operate the NBP button panel using
the factory firmware version. If you want to use the factory
default firmware version, you must upload that version again
(see the Toolbelt Help File or Global Configurator Help File
for firmware upload instructions).
The button panel reverts to the factory
default firmware. Event scripting does not start
if the unit is powered on in this mode. All user
files and settings such as button configurations,
adjustments, and IP settings are maintained.
NOTE: To return the unit to the firmware
version that was running prior to the
reset, cycle power to the unit.
Toggle DHCP Client
Enable or
disable the
DHCP client
To enable or disable the DHCP client for the LAN port:
1. Press the
Reset
button five times (consecutively).
2. Release the button. Do not press the button within 3 seconds
following the fifth press.
• The
Reset
LED blinks 6 times if the DHCP
client is enabled.
• The
Reset
LED blinks 3 times if the DHCP
client is disabled.
NOTES:
• By default DHCP is off and the unit uses a static IP address.
• When you disable DHCP, the unit reverts to using the previously-set static IP address.
Reset Network Settings
Reset network
settings and
port maps to
factory defaults
without
affecting
user-loaded
files
To reset all network settings:
1. Press and hold the
Reset
button for about 6 seconds until
the
Reset
LED blinks twice (once at 3 seconds, again at
6 seconds).
2. Release and press the
Reset
button momentarily (for
<1 second) within 1 second*.
* Nothing happens if the momentary press does not occur within
1 second.
NOTE:
This reset also turns DHCP off.
Reset Network Settings mode:
• Sets the IP address back to factory default
(192.168.254.253)
• Sets the subnet back to factory default
(255.255.255.0)
• Sets the default gateway address to the
factory default (0.0.0.0)
• Sets domain and host names to factory
default
• Turns DHCP off
• Disables 802.1X authentication.
Full Factory Reset
Start over with
configuration
and uploading
To reset the unit to all factory default settings:
1. Hold down the
Reset
button for about 9 seconds until the Reset
LED blinks three times (once at 3 seconds, again at 6 seconds,
again at 9 seconds).
2. Release and press the
Reset
button momentarily (for
<1 second) within 1 second*.
* Nothing happens if the momentary press does not occur within
1 second.
Full Factory Reset mode performs a
complete reset to factory defaults (except
the firmware).
• Does everything Reset Network Settings
mode does
• Removes (clears) all user-loaded files and
configurations from the NBP
• Clears driver-port associations (Ethernet)
and port configurations
NOTES:
• After performing a Reset Network Settings or a Full Factory Reset, use Toolbelt to set the IP address
again for use on your network.
• The factory configured passwords for this device have been set to the device serial number. Passwords
are case sensitive. Performing a Full Factory Reset sets the passwords to
extron
.
Rev. E: Per discussion w/John
S, Carolina, B., Tameem B,
deleted “quickly” from the
LED blinking behavior in step
1. Changed LED behavior
again based on info from
Tameem and discussions with
John S.
Rev. D: Added a bullet point noting that
802.1X authentication is disabled by
the Reset All IP Settings reset.
Rev. F: Changed “Reset All IP Settings”
to “Reset Network Settings” and
changed “Reset to Factory Defaults”
to “Full Factory Reset” per Barry Ader,
James Prieto, Alberto Cervantes.
Rev. C: Added a note about
the factory configured
password being set to the
device serial number.
