Network Button Panels • Operation 50
Reset Features and Resetting the Unit
Locating the Reset Button and LED
The
Reset
button and LED (shown at right) are located on the
front panel of each decorator-style or US gang series unit, behind
the wallplate or faceplate (see gure 53,
F
, on page 45), on
the rear panel of each EU model (see gure 54,
F
), or on the
bottom panel of the NBP 1200C (see gure 55,
F
).
Resetting the Unit
There are several reset modes that are available by pressing the
Reset
button. The
Reset
button is recessed,
so use an Extron Tweeker, a pointed stylus, or a ballpoint pen to access it. See the reset modes table on the
following page for a summary of the modes.
ATTENTION:
• Review the reset modes carefully. Using the wrong reset mode may result in unintended loss of flash
memory programming, port reassignment, or a unit reboot.
• Analysez minutieusement les différents modes de réinitialisation. Appliquer le mauvais mode de
réinitialisation peut causer une perte inattendue de la programmation de la mémoire flash, une
reconfiguration des ports ou une réinitialisation de l’unité.
NOTE: If you press and hold the
Reset
button continuously, the LED blinks every 3 seconds, and the unit
enters a different mode, from the Reset Network Settings mode through the Full Factory Reset mode. For
Full Factory Reset mode the LED blinks three times, the third blink indicating the last mode. The modes are
separate functions, not a continuation from one mode to the next.
RESET
RESET
US Gang or EU
NBP
Decorato
r
-style
NBP
RESET
NBP 1200C
