Network Button Panels • Hardware Features and Installation — NBP 1200C 29
Overall Configuration Procedure, NBP 1200C
Step 10: Configure the IP settings of each
NBP and of the control processor.
See the network
communication
setup instructions
Create a new GC Professional or GC Plus project
and add the control processor to it.
Congure ports.
Add NBP button panels and congure the buttons.
Step 12: Test the system, make
adjustments, nalize conguration.
Save the project.
Step 9: Cable the NBPs and the control processor,
then apply power.
Cable other devices.
Step 2: Prepare the installation site, cut the table or furniture.
Step 3: Assemble AAP, pass-through, and power modules.
Step 4: Install modules and a Retractor bracket.
Step 6: Mount the NBP1200C to the table.
Step 7: Install Retractors.
Step 8: Install cables in the Cable Cubby enclosure
Step 1: Get ready.
Step 5: Change buttons or faceplates, if desired.
Create monitors, schedules, timers, macros,
and local variables.
Build and upload the conguration to
the control processor.
If desired or required, install a new security
certicate (via Toolbelt).
Within Global Configurator
(GC Professional or
GC Plus mode):
Step 11
Figure 35. Overall Installation and Configuration Steps for the NBP 1200C
35
network
communication
setup instructions
on page41.
