MLC Plus 84 Series • Introduction 3
Once you have set up how you want it to work (set up IP addresses and functions, assigned
drivers to ports, configured relays and digital input), that information is saved to a project
configuration file that is built and uploaded into the MLCPlus.
The MLCPlus84 Series integrates seamlessly with Extron GlobalViewer Enterprise (GVE)
software and Extron Control apps for remote control applications.
Features
General features
• Flexible options for device control
• Controlling the MLC — All models offer front panel controls. The MLC can also
be controlled using Extron Control apps, or digitalinput signals.
• Controlling other devices — The MLCPlus84Series models offer RS-232
and IR-based control, digital input, and relay controls. They also include a port for
volume control of an Extron audio amplifier.
• A variety of mounting options — The MLC can be mounted in furniture or a wall, in
a lectern, or in a surface mount box, depending on the model and its faceplate.
• Support for Power over Ethernet (PoE) — The MLC supports power over Ethernet,
which allows the control processor to receive both power and an Ethernet connection
over a single connector.
• Support for an optional external power supply — The MLC also supports
connection to an optional external 12VDC power supply that accepts 100-240VAC,
50-60Hz input. The power supply is not included with the MLCPlus84.
Network and configuration features
• Global compatibility — The MLC uses industry standard Ethernet communication
protocols, including DHCP, DNS, HTTP, HTTPS, ICMP, NTP, SFTP, SMTP, SNMP, SSH,
TCP/IP, and UDP/IP.
• Embedded web pages — The MLCPlus84 embedded web pages include basic
information about the device, time, network settings, firmware version, and information
on the projector or other devices in the configuration for that unit.
• Network connection —
• The MLCPlus84D supports 10Base-T up to gigabit (1000Base-T) Ethernet
communication.
• The MLCPlus84EU and MLCPlus84MK support 10Base-T up to 100Base-T
Ethernet communication.
• Remote equipment management — The IPLinkPro connection on the MLCPlus
allows you to remotely manage, monitor, and control several Ethernet-enabled products
such as projectors, cameras, video conferencing equipment, switchers, and other AV
equipment. The MLC provides support for the following:
• TCP, UDP, and HTTP connections
• Password protection using secure communication
• Up to eight or four Ethernet devices at a time depending on the configuration mode
(GCProfessional or GCPlus)
• Connection via IP address or host name
• Multi-level password protection — Allows security to be set based on user roles.
• System asset management — The configured system and controller allow you to
control, monitor, and schedule various functions of devices in the system.
Rev. D, 08/2018:
harmonized
wording with the
IPCPPro/ IPLPro
user guides.
Each MLCPlus84IPSeries controller offers up
to 512MB of flash memory for storing Extron
GlobalViewer and user-supplied web pages,
configuration settings, and device drivers.
Data in flash memory is served at a transfer
rate of 6 Mbps (megabits per second).
SDRAM: 512 MB
Flash: 512 MB
IFF the embedded web page is ever updated to make the link work,
add the following text:
• If the unit is configured to work with Extron Control, you
can access the virtual user interfaces from a link in the
embedded web page.
Rev. H: Added text
about accessing
Extron Control from
the embedded web
page.
