MLC Plus 84 Series • Introduction 1
Introduction
This section covers the following basic information you should know about this guide and
the product before installation:
• Before You Begin
• About the MLCPlus84Series
• Application Diagram
• Device Control
• About Global Configurator (with GCProfessional and GC Plus Modes)
• PC System Requirements
Before You Begin
What This Guide Covers
This user guide provides instructions for an experienced installer to install an Extron
MLCPlus84Series IP Link Pro Controller. This guide includes detailed information and
recommends best practices for cabling the controller. It provides a brief overview of the
configuration process, and reference information.
Configure the controller using Extron Global Configurator software running in Global
Configurator Professional (GCProfessional) or Global Configurator Plus (GC Plus) mode,
and Toolbelt. This guide does not contain instructions on detailed software-related setup
steps or details of configuration within the software: those are covered in the Global
Configurator Help File and help files for related programs. The software help files describe
how to use each program to download drivers, add AV devices to a configuration, configure
basic functions, and set up schedules, macros, e-mail alerts, button configurations, and the
like.
Conventions Used in This Guide
• Throughout this guide the MLCPlus84Series products are also referred to as the
“MLCPlus,” “MLCPlus84,” or “controller.”
• Global Configurator software is referred to as “GC,” which can be run in Global
Configurator Professional mode (“GCProfessional”) or Global Configurator Plus mode
(“GCPlus”).
• The GlobalViewer Enterprise application is sometimes referred to as “GVE.”
• Unless otherwise noted, in images of software or web pages, circled numbers
correspond to the like-numbered procedural steps.
Important Information You Need Before Installation
The MLCPlus Series controllers work differently from the previous generation of IPLink
products. The order and types of setup tasks are important. Pay close attention to them.
Follow the setup checklist in the Hardware Features and Installation section starting on
page6.
