MLC Plus 84 Series • Hardware Features and Installation 8
Installation Step 1: Get Ready
Use the following checklist to prepare for the installation.
Familiarize yourself with the features of the controller (see Front Panel Features on
page30 and Rear and Side Panel Features and Cabling on page18)
Download and install the latest version of the following:
Toolbelt software — for discovering the controller and other control products on
the network, for managing core settings, and for upgrading firmware when needed
Global Configurator software — for configuring the control system
IPLinkPro device drivers — for use with GC, to make control of other devices possible
All are avail able from www.extron.com (see Locating Software, Firmware, and
Driver Files on the Extron Website on page40).
Obtain network information for the unit from the network administrator. You need the
following details for each IPLinkPro device such as the MLCPlus:
DHCP setting (on or off) Subnet mask User name
Device (MLC Plus 84) IP address Gateway IP address Passwords
NOTE: If DHCP is on, you do not need the IP addresses and subnet mask.
Write down the MAC address of each IPLinkPro device (such as the MLC Plus 84) to be used.
Obtain model names and setup information for devices the MLC Plus 84 is going to control.
Each controller comes with a factory-installed Secure Sockets Layer (SSL) security
certificate. If you intend to install a different SSL certificate, contact your IT department
to obtain the certificate or for instructions on how to obtain one. See Secure Sockets
Layer (SSL) Certificates on page45 for requirements and guidelines regarding SSL
certificates.
IEEE 802.1X authentication is also supported once enabled. For systems that are going
to use IEEE 802.1X security, obtain a PEM-encoded security certificate and private key
(see IEEE 802.1X Certificates on page45) from your IT department.
Installation Step 2: Prepare the Installation Site
Steps and hardware required depend on the model being installed. See the following
sections for details:
• MLCPlus84D Site Preparation on page10
• MLCPlus84EU and MLCPlus84MK Site Preparation on page11
ATTENTION:
• Installation and service must be performed by authorized personnel only.
• L’installation et l’entretien doivent être effectués uniquement par un technicien
qualifié.
• Extron recommends installing the MLC Plus 84 D into a grounded, UL Listed
electrical junction box.
• Extron recommande d’installer le MLC Plus 84 D dans une boîte de dérivation
électrique mis à la terre, certifiée UL.
• Extron recommends installing the MLC Plus 84 EU/MK into a grounded electrical
junction box.
• Extron recommande d’installer le MLC Plus 84 EU/MK dans une boîte de
dérivation électrique mis à la terre.
Rev. C, 4/2017: Updated
description of what Toolbelt
does, per IPCP guide
Turned bulleted list of software
into a checkbox list.
Rev. G: Added note about
not needing IP addresses
if DHCP is on.
Rev. G: Replaced
“will” with “is
going to”.
Rev. G: added a checklist item for the
802.1X certificate and key.
Rev. F: Changed French
text in the first attention
per Sean G.’s setup guide
review & latest translation
file.
It no longer seems to be a
direct translation of the
English.
Rev. F: Changed French text in
2nd & 3rd table rows per latest
translation file.
