• MLC 62 RS MK — UK model. Controls devices by RS-232, IR, relays, and digital
input; has a standard MK sized frame and fits into a standard one-gang MK electrical
box.
• MLC 64 RS VC D — US model. Controls devices by RS-232, IR, relays, and digital
input; has a two-gang decorator-style faceplate and fits in a two-gang US electrical
box. Contains a volume control module with an analog potentiometer for volume
control of an Extron amplifier.
NOTE: Only an Extron amplifier with remote volume control capability can be used
with this model.
VOLUME
Extron
DISPLAY
ON
OFF
VIDEO
PC
VOLUME
Extron
DISPLAY
ON
OFF
PC
VIDEO
LAPTOP
MUTE
MLC 62 IR D MLC 62 RS D
Extron
VOLUME
DISPLAY
ON
OFF
LAPTOP MUTE
PC VIDEO
Extron
VOLUME
DISPLAY
ON
OFF
VIDEO
PC
MUTE
LAPTOP
MLC 62 RS EU MLC 62 RS MK
AUX
LAPTOP
PC
MUTE
Extron
DISPLAY
VOLUME
ON
OFF
VIDEO
MUTE
V
O
LUM
E
MLC 64 RS VC D
Figure 1. MLC 60 Series Models
MLC 60 Series MediaLink Controllers • Introduction 2
