IPCP Pro Series • Hardware Features and Installation
11
Configure or Program the Control Processor, Touchpanels, and Network Button Panels
• If TouchLink Pro touchpanels are part of the system, start and use GUI Designer to design, save, and
build the graphical user interface (GUI) layout for the touchpanels (see the GUI Designer Help File for
instructions).
NOTE: To redeem (activate) a LinkLicense, go to www.extron.com/llredeem and follow the online
instructions.
A LinkLicense unlocks features that add convenience, expand system options, and enhance the
capabilities of your Extron products. For IPCP Pro systems, a LinkLicense allows you to use a mobile
device or computer as the primary control interface in an Extron control system where a TouchLink Pro
touchpanel may not be present.
• If using GC, create a new GC Professional or GC Plus project and configure the control processor and
other IP Link Pro devices. The configuration tells the control processor:
• How its ports function • What to monitor
• How to control other products • When to do things
• Which touchpanels to interact with • Whom to notify, how, and under what circumstances
• Configure ports on the control processor:
• Select device drivers and link them to each serial, IR/serial, or Ethernet port.
• Select settings (serial protocol, relay behavior, digital I/O or flex I/O settings, AC output settings) as
needed.
• Add eBUS devices and set them up:
• Ensure that the hardware address (eBUS ID) set on each device is distinct and matches the address
used in the configuration.
• Assign button functions as desired.
• Add Network Button Panels (NBPs) and set them up. Assign button functions as desired.
• Set up monitors, schedules, macros, and local variables.
• Add touchpanels and set them up:
• Upload the GUI Designer layout to the Global Configurator project.
• Assign any appropriate functions, monitors, or schedules to the touchpanels and their buttons.
• If not using GC Professional or GC Plus, use ControlScript programming software to program the
control system as desired.
• Program ports on the control processor:
• Program each serial, IR/serial, or Ethernet port.
• Program relay behavior, digital I/O, flex I/O, and AC output settings as needed.
• Add eBUS devices and set them up:
• Ensure that the hardware address set on each device is distinct and matches the addresses
programmed for them in the IPCP.
• Program button functions as desired.
• Add Network Button Panels (NBPs) and set them up. Assign button functions as desired.
• Add touchpanels and set them up:
• In Global Scripter, drag the GUI Designer layout file into the
System Manager
window. Click on the
touchpanels in the project and select the layout file to be associated with each panel.
Or
• In ControlScript Deployment Utility, make sure the GUI Designer layout file is present in the
Layout
folder of the project. In the project descriptor JSON file, set the layout file value for the touchpanels in
the system to match the file name of the GUI Designer file you wish to be associated with each panel
• Program functions, monitors, or schedules to the touchpanels and their buttons.
For rev. J: Added
reference to network
button panels.
Rev. M: Changed “configuration” to
“Designer layout” per Francisco Soto.
Rev. M: Changed Global
Scripter to from ControlScript
programming software.
For rev. J: Added
reference to
network button
panels.
Rev. M: Changed touchpanel
setup instructions for GS
and CSDU per Francisco
Soto.
