IPCP Pro Q xi and xi Series • Hardware Features and Installation 21
GTx Rx GTx Rx
COM 2 COM 3
RELAYS
21 43 CC
COM 1
GTx Rx
RTS CTS
LAN
IR/SERIAL
1
S G
2
S G
1 2 3 4 G
DIGITAL I/O
IR
R
eBUS
+V +S -S G
PWR OUT = 6W
IPCP PRO 355DRQ xi
12V
1A MAX
POWER
AV LAN
Figure 15. The IPCP Pro 355DRQ xi Mounted on a DIN Rail, Before Cabling
Mounting the IPCP Pro Matrix Q xi Into a Matrix Switcher
The IPCP Pro Matrix Q xi mounts within an Extron FOX3 matrix switcher using the captive screws (
C
in
gure 19 on page 25). See the “Maintenance and Modications” sections of the FOX3 Matrix Series User
Guide or FOX3 Matrix Series Setup Guide (available at www.extron.com) for mounting instructions
15
Rev. C: Addded FOX3 Hanoi
mounting instructions here.
Ports, Addressing, and Connections
ATTENTION:
• Installation and service must be performed by experienced personnel.
• L’installation et l’entretien doivent être effectués par du personnel expérimenté.
The quantity of ports and corresponding front panel LEDs diers among IPCP models, but the functions of each
type of port and their LEDs are identical for any model that includes that type of port.
