IPCP Pro Q xi and xi Series • Hardware Features and Installation 9
Hardware Features and
Installation
This section covers the following material:
• Setup Checklist: How to Proceed With Installation — A checklist of tasks to guide you through installation
•
Network Communication Setup — A flowchart guide to network settings configuration
• Front Panel Features — Locations and some descriptions of items on the front panel
• Mounting the IPCP Pro xi Series — Brief guidelines for mounting
• Ports, Addressing, and Connections — Locations, descriptions, and cabling notes for rear panel features
and corresponding front panel indications
• Resetting the Unit — Information about the available reset modes and how to reset the IPCP
Pay careful attention to the order and types of setup tasks. Follow the setup checklist in this guide or in the setup
guide and keep it with you for reference throughout the installation and conguration process.
Setup Checklist: How to Proceed With Installation
Get Ready
• Familiarize yourself with the features of the control processor (see Front Panel Features on page 13
and Ports, Addressing, and Connections on page 21) and of any TouchLink Pro touchpanels or button
panels that will be part of the system.
• Download and install the latest version of the following:
• Toolbelt software — for discovering the control processor and other control products on the network, for
managing core settings, and for upgrading firmware when needed
• Global Configurator (GC) software — for configuring the control system
• Global Scripter software or the ControlScript Deployment Utility (ControlScript Pro xi software) —
for programming the control processor (as an alternative to GC)
• PCS Product Configuration Software version 4.5 or higher — for setting the IP address for any
IPCP Pro Q xi model with AV LAN ports if the ports are currently set to the default IP addresses
• GUI Designer software — for designing layouts for Extron TouchLink Pro touchpanels and third-party
touch interfaces
• IP Link Pro device drivers — for use with GC, to make control of other devices possible
• IR Learner Pro software — for use with models that have IR receiver ports, to create your own IR drivers
using the remote control of an AV device, if drivers are not already available from Extron
All are avail able from www.extron.com (see Locating Software, Firmware, and Driver Files on the Extron
Website on page 55).
• Obtain network information for the unit from the network administrator. You need the following details for each
IP Link Pro xi device:
• DHCP setting (on or off) • Gateway IP address
• Device (IPCP Pro, TouchLink Pro, IPL EXP) LAN IP address • Username
• AV LAN IP address (for models with AV LAN)
• Subnet mask
NOTE: If DHCP is on, you do not need the IP addresses and subnet mask.
• Passwords
Rev. D: Added ControlScript
Deployment Utility and
replaced checkboxes with
bullets..
Rev. B: Added note about
not needing IP addresses
if DHCP is on.
