HAE 100 4K Plus • SIS Commands 11
Command ASCII
Command
(host to unit)
Response (unit to host) Additional Description
Audio
Disable TMDS Audio Output
E
O0AFMT
}
AfmtO0
]
Enable TMDS Audio Output
E
O1AFMT
}
AfmtO1
]
Default
TMDS Audio Output Status
E
OAFMT
} X#]
Set Analog Output Mode
E
S
X1^
AFMT
}
AfmtS
X1^] X1^
= 1 (stereo - default),
2 (dual mono)
View Analog Output Mode
E
SAFMT
} X1^]
Audio Mute Per Output
X1&
*
X#
Z Amt
X1&
*
X#] X1&
= 1 (analog), 2 (S/PDIF)
Audio Mute All Outputs
X#
Z Amt
X#]
View Audio Mute Status
Z
X#
•
X#]
Amt
X#
•
X#]
Analog out • S/PDIF out
Verbose mode 2/3
Info/Other
Information
I
AudI
X!
•
Sig
X#
•
X#
•
HdcpI
X1@
•
HdcpO
X1#]
Input audio, input/output signal,
and HDCP status
KEY:
X!
= Input audio status:
0 = No audio detected or detected audio cannot be de-embedded
1 = S/PDIF Bitstream audio detected, 2 = 2-Ch LPCM detected
X#
= 0 = off, disabled or not detected
1 = on, enabled, or detected
X1@
= Input HDCP status:
0 = No active video source detected
1 = Video detected without HDCP (not encrypted)
2 = Video detected with HDCP (encrypted)
X1#
= Output HDCP status:
0 = No sink detected
1 = Non-HDCP sink detected (sink is not HDCP compliant)
2 = HDCP sink detected not encrypted
3 = HDCP sink detected and encrypted
X1^
= Analog audio output configuration:
1 = Stereo (default)
2 = Dual Mono
X1&
= Audio output:
1 = Analog output
2 = S/PDIF output
