FOX3SR 301 and FOX3SR311 Scaling Receivers • Equipment Mounting 48
Equipment Mounting
This section provides procedures for mounting the FOX3SR 301 and FOX3SR311 scaling
receivers.
Mounting the Scaling Receiver
ATTENTION:
• Installation and service must be performed by authorized personnel only.
• L’installation et l’entretien doivent être effectués par le personnel autorisé
uniquemen
t.
The 1-inch high, half rack width scaling receivers can be placed on a table, mounted in a
rack, or mounted under a desk or table. The scaling receivers can also be mounted on a
projector bracket.
Tabletop Use
Affix the included rubber feet to the bottom of the unit and place it in any convenient
location.
Mounting kits
Mount the unit using any optional compatible mounting kit listed on the Extron website
(www.extron.com), in accordance with the directions included with the kit. For rack
mounting, see “UL Rack-Mounting Guidelines,” below.
