FOX3SR 301 and FOX3SR311 Scaling Receivers • SIS Configuration and Control 21
SIS Configuration
and Control
This section describes the remote control operation of the FOX3SR301 and FOX3SR311
scaling receivers, including:
• Host Control Ports
• Simple Instruction Set Control
• Command and Response Table for SIS Commands
The FOX3 receivers can be configured using SIS commands, PCS, or embedded web
pages. The receivers can also be controlled using SIS commands or PCS. Configure and
control the FOX3 receivers remotely via a host computer or other device (such as a control
system) by connecting to the rear panel RS‑232 port, LAN port, or the front panel USB port
of the FOX3 device.
NOTE: SIS commands and Product Configuration Software functions are receiver
specific or may have different responses depending on the unit connected. Connect
to the appropriate device for the command to work properly or to get the expected
response.
Host Control Ports
Rear Panel RS-232 Port
The FOX3 devices have a rear panel serial port (see figure2,
H
on page5) that can
be connected to a host device such as a computer running Extron DataViewer, available
at www.extron.com. The port makes serial control of the FOX3 device possible. Use the
protocol information listed below to make the connection.
The protocol for the serial ports is as follows:
• 9600 baud • no parity • 8 data bits
• 1 stop bit • no flow control
Front Panel Configuration USB Port
The front panel mini B USB Configuration port (see figure9,
B
on page12) can be
connected to a host computer for configuration using SIS commands via an SSH client and
IP address 203.0.113.22 on port 22023.
